Product Summary:

The Victron Cerbo GX is a powerful system communication and monitoring hub designed to provide complete control over Victron-based energy systems from anywhere in the world. Serving as the latest evolution in Victron’s GX line, the Cerbo GX connects all system components into one intelligent interface, allowing users to maximize performance, efficiency, and reliability across off-grid, mobile, and residential ESS installations.



Through the Victron Remote Management (VRM) portal and VictronConnect app, users can monitor battery state of charge, power consumption, solar production, generator status, tank levels, and temperatures in real time. Advanced control features include remote configuration, generator auto-start/stop logic, shore power current limits, alert notifications, and system diagnostics. Powered by a dual-core processor with dual CANBus ports, the Cerbo GX supports large-scale systems, including up to 25 VE.Can solar chargers, and ensures seamless operation during grid outages by prioritizing battery backup and self-consumption. Compact, installer-friendly, and highly scalable, the Victron Cerbo GX is the central brain for smart, connected energy systems.

Features

  • Remote Console Monitoring
  • Built-In WiFi Access Point
  • WiFi & Bluetooth LED Indicators
  • Ethernet, Micro SD, & USB Ports
  • Additional BMS-Can Port
  • Tank Level & Temperature Sense Inputs
  • Dual Core Processing Unit
  • Lightweight & Compact
  • Installer Friendly Design

Inverter Downloads

SKU#:INV019
Spec Sheet:DownloadDOWNLOAD

Inverter Specifications

Supply Voltage:8V – 70V DC
Power Draw:2.8W @ 12V
Operating Temperature Range:-4ºF – 122ºF (-20ºC – 50ºC)
Protection Rating:IP20
Resistive Tank Level Inputs:4
Temperature Sense Inputs:4
Digital Inputs:4
Relays:2 x NO/NC
VE.Direct Ports:3 (isolated)
Max. VE.Direct Devices:15
VE.Bus Ports:2x RJ45 (paralleled, isolated)
VE.Can:Yes (non-isolated)
BMS-Can Port:Yes
Bluetooth:Yes
Depth:1.9 in
Width:6 in
Height:3.1 in
Certifications:IEC 62368-1, EN 301489-1/17, & ECE R10-6
×
