Product Summary:
The EG4 314Ah WallMount Indoor LiFePO₄ Battery is a high-capacity, UL-certified energy storage solution designed for residential and commercial ESS applications. Delivering approximately 16kWh of storage, it provides reliable, long-lasting performance for home backup, energy savings, and off-grid systems.
Built with advanced LiFePO₄ battery chemistry, this system offers 8,000+ cycles at 80% depth of discharge, ensuring exceptional lifespan and value. An intelligent Battery Management System (BMS) with real-time monitoring and an integrated LCD touchscreen allows for easy system visibility and control.
Designed for safety and performance, the battery includes automatic self-heating for cold environments and an emergency stop (E-Stop) for rapid shutdown when needed. With RS485 and CANBus communication, it integrates seamlessly with leading hybrid inverters for flexible grid-tied and off-grid installations.
Ships From: Texas, USA
Warranty: 10 Years
Support: Lifetime USA-Based Tech Support
Compatibility
UL 9540 Certified + Closed-Loop Communication (Grid-Tied):
-
EG4 FlexBoss18
-
EG4 FlexBoss21
Closed-Loop Communication (Off Grid Non-UL 9540 Installs):
-
All BigBattery APEX Inverters
-
All EG4 Inverters
Key Features
- ~16kWh LiFePO₄ Battery – High-capacity, safe lithium storage
- 8,000+ Cycle Life – Long-lasting performance at 80% DoD
- UL-Certified Design – Built for safe, code-compliant installations
- Advanced BMS Monitoring – Real-time performance tracking and protection
- LCD Touchscreen Display – Easy system control and diagnostics
- Automatic Self-Heating – Reliable operation in cold environments
- Emergency Stop (E-Stop) – Rapid shutdown for enhanced safety
- RS485 & CANBus Communication – Seamless inverter integration
- Wall-Mount Indoor Design – Clean installation for homes and commercial spaces
- Maintenance-Free Operation – No routine servicing required
A high-capacity, reliable battery solution built for long-term performance, safety, and energy independence.
48V WallMount 314Ah All-Weather Battery
Choose Your Inverter Option*
Choose Your Battery Option*
Choose Your Battery Quantity*
Standard
Large
Complex
Introducing the WallMount 314Ah Batteries!
EG4 is proud to announce the next generation of our WallMount batteries with our 314Ah Indoor and All Weather versions! On top of the capacity improvements over our previous batteries, the WallMount 314Ahs have newly developed B<S functions, including WiFi/Bluetooth connectivity, active cell balancing logic, compatibility with our other WallMount batteries, and much more. They utilize the same quick connection terminals for rapid installation but have an additional bolt-style terminal for adding any ring connection necessary (such as a a classic Chargeverter).
The WallMount 314Ah batteries are compatible with the 280Ah form factor, so they will slot into existing systems easily. They pair well with the FlexBOSS21 and 18kPV when looking for whole home ESS solutions.
Battery Downloads
PENDINGPENDINGPENDINGPENDINGPENDINGBattery Specifications
Introducing the WallMount 314Ah Batteries!
EG4 is proud to announce the next generation of our WallMount batteries with our 314Ah Indoor and All Weather versions! On top of the capacity improvements over our previous batteries, the WallMount 314Ahs have newly developed B<S functions, including WiFi/Bluetooth connectivity, active cell balancing logic, compatibility with our other WallMount batteries, and much more. They utilize the same quick connection terminals for rapid installation but have an additional bolt-style terminal for adding any ring connection necessary (such as a a classic Chargeverter).
The WallMount 314Ah batteries are compatible with the 280Ah form factor, so they will slot into existing systems easily. They pair well with the FlexBOSS21 and 18kPV when looking for whole home ESS solutions.
