SHOP NEXT-GEN SOLUTIONS
Our FALCON Elite is being replaced with 2nd Generation alternatives with advanced features and protections. If you're looking to take your cart to the next level, shop the EAGLE 2 & HUSKY 2 today!
NEXT-GEN LITHIUM UPGRADES FEATURING
- IP65+ Protection Ratings
- CANBus Communications
- Automatic Self-Heating
- LED Capacity Meters
SHOP ALL GOLF BATTERIES
-
48V 2X EAGLE 2 KIT
LiFePO4 - 64Ah - 3.26kWh
K0978$1,845 -
48V 1X HUSKY 2 KIT
LiFePO4 - 100Ah - 5.12kWh
K0972$2,315
48V 2X HUSKY 2 KIT – EG4 6K OFF-GRID INVERTER
$5,519
12 Year Warranty
Applied To Batteries Only
[pr_view_popup_btn]
FHSKY-48051-G2
INV026
CBL099
CBL092
48V 2X HUSKY 2 KIT – EG4 6K OFF-GRID INVERTER
$5,519
Included Components
2 × 48V HUSKY 2 - LiFePO4 - 100Ah - 5.12kWh
1 × EG4 6kW (8kPV) OFF-GRID INVERTER
1 × Parallel Comm Cable
1 × 4AWG (Black and Red) 21 inches Ring to Ring Terminal Cable
[pr_view_size_popup]
Included Components
2 × 48V HUSKY 2 - LiFePO4 - 100Ah - 5.12kWh
1 × EG4 6kW (8kPV) OFF-GRID INVERTER
1 × Parallel Comm Cable
1 × 4AWG (Black and Red) 21 inches Ring to Ring Terminal Cable
SECOND GENERATION POWER STORAGE IS HERE! This 48V 10.24kWh LiFePO4 HUSKY 2 Kit is the latest and greatest from BigBattery, providing a robust solution, with unmatched reliability and efficiency, for any off-grid power system, emergency backup, or mobile power setup in your RV or camper van.
The HUSKY 2 is our most energy-dense 48V solution to date, designed to provide ultimate peace of mind during operation, whether that’s in your home during a blackout, or while out boondocking in the countryside! From its Tier 1 LFP cells to its generous operating parameters and wide temperature range, this battery redefines versatility and durability when it comes to lithium power storage, and boasts comprehensive BMS protections against Over/Under Voltage and Over Current statuses, as well as a thermal management system that affords a generous operating temperature range. But that’s not all!
The HUSKY 2 comes with state-of-the-art features to enhance the safety and visibility of your power. Not only is it housed in an IP65-rated, vibration-resistant casing, and equipped with an advanced BMS capable of auto-balancing cells, but it also boasts a self-heating function which supports cold weather charging, ensuring you have reliable power through every season. Plus, the HUSKY 2 features full CANBus & RS485 communication protocols, and we pair these HUSKY 2s with a cutting-edge 6000W EG4 split-phase inverter, equipped with its own in-depth LCD display, so you can always stay up to date on the status and performance of your power. This multifunctional inverter and charger boasts advanced parallelability up to 96kW, built-in circuit breakers, smart load control, variable working modes, and an integrated UPS module, along with the ability to handle PV arrays of up to 8000W, making this unit the perfect companion for your HUSKY 2s.
Equipped with the 48V HUSKY 2, you’ll be saving space and weight no matter the application, and you can rest easy knowing you’re powered and prepared day in and day out. Shop the all-new 48V HUSKY 2 & HUSKY 2 Kits today!
IP65 Protection Rating
AUTOMATIC
SELF-HEATING
SELF-HEATING
CANBUS & RS485
COMMUNICATIONS
COMMUNICATIONS
SIMPLE
INSTALLATION
INSTALLATION
Single Battery Tech Specs
| SKU: | FHSKY-48051-G2 |
| System Voltage: | 48V |
| Nominal Voltage: | 51.2V |
| Chemistry: | LiFePO4 |
| kWh Capacity: | 5.12kWh |
| Ah Capacity: | 100Ah |
| Charging Voltage Range: | 55.6 - 57V |
| Max Charge Voltage: | 58.8V |
| Operating Voltage Range: | 48 – 57V |
| Suggested Low Voltage Cutoff: | 48 – 50.8V |
| BMS Cutoff Range: | 42 - 47V |
| Cell Configuration: | 16S |
| Max Continuous Discharge Current: | 150A |
| Recommended Continuous Discharge Current: | 100A |
| Max Continuous Power: | 7500W |
| Recommended Continuous Power: | 4000W |
| Max Discharge Peak Current: | 225A (Max 5 seconds) |
| Max Charge Current: | 100A |
| Charge Temperature Range: | -4°F - 113°F (-20°C - 45°C) |
| Discharge Temperature Range: | -4°F - 122°F (-20°C - 50°C) |
| Optimal Discharge Temperature Range: | 59°F - 95°F (15°C - 35°C) |
| Storage Temperature Range: | -4°F - 122°F (-20°C - 50°C) (Max 6 months) |
| Weight: | 100 lb (45.4 kg) |
| Depth: | 12.6 in (320 mm) |
| Width: | 18.1 in (460 mm) |
| Height: | 9.8 in (249 mm) |
| Max Connections: | Up to (16) Parallel |
| Protection Rating: | IP65 / NEMA 4X |
| Communications: | CANBus / RS485 |
| Self-Heating: | Yes |
| Spec Sheet: | Click Here |
| User Manual: | Click Here |
| Safety Data Sheet: | Click Here |
| CE Certificate: | Click Here |
| UN38.3 Certificate: | Click Here |
Inverter Specs
AC INPUT & OUTPUT
| AC Voltage: | 120V AC / 240V AC |
| AC Frequency: | 50 Hz / 60 Hz |
| Max. Continuous AC Current: | 37.5A @ 240V |
| Max. AC Input Power: | 9000W |
| AC Bypass: | 50A |
| Output Voltage: | 120V AC / 240V AC |
| Output Frequency: | 50 Hz / 60 Hz |
| Max. Continuous Output Current: | 25A @ 240V |
| Output Power: | 6000W |
| Surge Capacity: | 12000W (3.5 sec) / 11000W (5 sec) |
| Power Factor: | 0.99 (Full Load) |
| Reactive Power Adjustment Range: | -0.8 - 0.8 Leading Adjustable |
| Total Harmonic Distortion: | <3% |
| Switching Time: | <15 ms (Single) / <30 ms (Parallel) |
PV INPUT
| No. of MPPTs (Inputs per MPPT): | 2 (1) |
| Max. Input Current: | 17A / 17A |
| Max. Short Circuit Input Current: | 25A / 25A |
| DC Input Voltage Range: | 100 - 480V DC |
| Start Up Voltage: | 100V DC ± 10V DC |
| MPPT Operating Voltage Range: | 120 - 385V DC |
| MPPT Voltage: | 320V DC |
| Max. PV Array Power: | 8000W (4000W per MPPT) |
| MPPT Efficiency: | 99% |
BATTERY
| Nominal Voltage: | 48V DC |
| Battery Voltage Range: | 46.4 - 60V DC |
| Max. Discharge Current: | 140A |
| Max. Charge Current: | 125A |
| DC Cut-Off Voltage: | 59V DC |
| DC Recovery Voltage: | 57.4V DC |
| Charge Cut-Off Voltage: | 58.4V DC |
OPERATING ENVIRONMENT & DIMENSIONS
| Operating Temperature: | 32ºF - 113ºF (0ºC - 45ºC) |
| Storage Temperature: | 5ºF - 140ºF (-15ºC - 60ºC) |
| Altitude: | <6,561 ft (2000 m) |
| Relative Humidity: | 5 - 95% |
| Typical Noise Emission: | <58 dB |
| Protection Rating: | IP20 |
| Max. Parallel Connections: | 16 |
| Weight: | 52.9 lbs (24 kg) |
| Depth: | 5.25 in (132 mm) |
| Width: | 18 in (457 mm) |
| Height: | 25.5 in (648 mm) |
| Spec Sheet: | Click Here |
| User Manual: | Click Here |
| Monitoring System Guide: | Click Here |
| Monitoring Adapter Installation Guide: | Click Here |
| UL1741 Certificate: | Click Here |
| Warranty: | Click Here |
Designed For 48V Applications
